Abrites - TN020 Toyota & Lexus Dashboard Calibration via Direct CAN Bus (RH850, Denso)

Abrites – TN020 Toyota & Lexus Dashboard Calibration via Direct CAN Bus (RH850, Denso)

The TN020 license is Abrites’ latest and most advanced solution for calibrating fully digital Denso instrument clusters with RH850 processors, found in Toyota and Lexus vehicles up to model year 2024. This cutting-edge procedure is performed within seconds via a direct CAN-Bus connection to the vehicle, ensuring quick, accurate, and secure results.

Functionality:

• Dashboard calibration for fully digital Denso clusters with RH850 processors

• Supports the latest Toyota and Lexus models with fully digital dashboards (no analog gauges or LED indicators)

Supported Vehicles Include:

• 2023 Toyota Corolla

• 2023 Toyota Corolla Cross

• 2023 Lexus LS 500

• Other Toyota & Lexus models up to 2024 equipped with RH850 fully digital dashboards

Required Hardware & Software:

• ABRITES Vehicle Diagnostics Interface (AVDI)

• Direct CAN-BUS/LIN-BUS Connection Cable Set (CB012)

• Extension Cable for Direct Connection to Toyota/Lexus Smart System with B9/BA (CB031)

• Active Annual Maintenance Subscription (AMS)

Procedure Notes:
The TN020 calibration process requires the CB012 and CB031 cables to establish a direct CAN-Bus connection to the vehicle through the Denso Smart System. An AVDI with an active AMS is mandatory for enabling and performing the operation.

With TN020, technicians can complete Toyota and Lexus dashboard calibration tasks efficiently, making it an essential tool for workshops dealing with the latest digital clusters.
